Coating Thickness Meter CM8829S CM-8829S manufacturer from China Guangzhou Landtek Measuring Instruments Co.Ltd.

Product Detail

Model No.: CM-8829S

Production Capacity: 2000/pcs/month

Delivery Date: 3--5days

type: separate type

resolution: 0.1 um/1 um

data output: USB,RS232C,Bluetooth

Means of Transport: Ocean,Land,Air

Packing: carton

Brand Name: landtek

measuring range: 0~1250 um / 0~50 mil

power supply: 4 x 1.5 V AAA (UM-4) Batter...

Coating thickness gauge
Wet film thickness gauge
Galvanized coating thickness gauge
Anodizing thickness gauge
Paint coating thickness gauge

Coating Thickness Meter CM-8829S

Applications:

Coating Thickness Meter CM-8829S has two measuring methods to choose.How to choose?

Measuring method:F probe

Coating:

*paint, plastic, porcelain enamel, copper, zinc, aluminium, chrome etc.(non-magnetic materials)

*alvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer,

copper tile, aluminium tile, some alloy tile, paper etc.

Base:iron, nickle etc.(magnetic materials)

Measuring method:N probe

Coating:anodizing, varnish, paint, enamel, plastic coatings, powder,etc.(non-conductive coatings)

Base:aluminum, brass, non-magnetic stainless steel, etc(non-magnetic materials)

Features:

* Two measuring methods: magnetic induction (F) and eddy current (N)

* Two measurement mode: Single and Continuous

(Notice:Continuous mode is convenient to measure the

coating thickness of curved objects and tiny objects.)

* Metric/imperial system selectable.

* Manual or automatic shut down.

* Automatic memory of calibration value,and automatic recognize the substrate.

* Operation process have buzzing reminder,while no buzzing in continuous mode.

* Use USB data output and RS-232 data output to connect with PC.

* Provide Bluetooth data output choice.

* Separate Type can provide several type probe, measure can be more flexibility.

Details:

Operating Principle	Magnetic Induction / Eddy Current (F / NF)
Measuring Range	0~1250 um / 0~50 mil
Resolution	0.1 um / 1 um
Min. Radius Workpiece	F Type: convex 1.5 mm / concave 25 mm NF Type: convex 3 mm / concave 50 mm
Min. Measuring Area	6 mm
Min. Sample Thickness	0.3 mm
Accuracy	± 1~3%n or ± 2.5 um
Auto Power Off
Metric / Imperial	Convertible
Battery Indicator	Low Battery Indicator
Operating Conditions	Temp. 0~40 °C, Humidity: 10~90 %RH
Power Supply	4 x 1.5 V AAA (UM-4) Battery
Dimensions	126 x 65 x 27 mm
Weight	115 g (Not Including Batteries)
